| Applications | Abdomen, OB/GYN, Vascular, Small parts (breast, testes, thyroid), Musculoskeletal, Conventional & Superficial, Pediatric, Basic Cardiac |
|---|---|
| Imaging technologies | i-Image, SRA, Compound imaging, THI |
| Display Modes | B, B/B, 4B, M, B/M, PW |
| Gray Scale | 256 Levels |
| Scanning Depth | 240mm Max (depend on the probe types) |
| Probe Frequency | 2.5 MHz - 11.0 MHz (Depend on the probe) |
| Cine Loop | 256 frames |
| Zoom | 4 steps |
| Software Packages | Dedicated measurement package: General, OB/GYN, URO, Cardiac, vascular, small parts |
| Archives Management | Patient information management, images record, exam report. |
| Power Supply | AC 100V-240V, 50Hz-60Hz |
| Standard Configuration | Main unit, 2 probe connectors, 3 USB ports, VGA port, Video port, LAN port, Full Screen Display Mode, i-Image, Chroma, SRA, Compound imaging, THI, 8G memory card, PW Mode, Built-in Battery (BT-2500) |
| Option | DICOM 3.0, Water-proof keyboard cover, Carrying Case (BG-100), Cart TR 9000, Support PC Printer (HP 1010 / HP 1020 Plus / HP Pro P1102W / HP Pro 200 M251n), Video Printer (SONY UP-X898MD) |
